Prima 100
€ 2.650,00
Discover the Aqua Broadcast PRIMA 100 FM transmitter – powerful performance in a compact design. Ideal for FM and digital radio. Order now for high-quality broadcasts!
Discover the Aqua Broadcast PRIMA 100 FM transmitter, an advanced, rugged, low-power transmitter with high-efficiency technology. With a broadband, tunable range between 88-108 MHz, installation is quick and easy. The clear LCD screen and front-mounted control buttons allow for effortless settings.
The compact 1RU design with 100 W output power includes a stereo encoder and offers versatile connectivity, including analog audio inputs, AES/EBU digital audio input, and MPX. Easily manage the PRIMA 100 remotely via WEB with a TLC/TLS secure connection or SNMP from any location with Internet access. With 365/7 broadcast reliability, the PRIMA 100 is suitable for a variety of applications.
PRODUCT SPECIFICATIONS
- Operating bandwidth: 87.5 ÷ 108 MHz
- Frequency stability: ± 1 ppm
- Output power: 100 W
- Output range: At least 10% of total maximum power
- Harmonic attenuation: ≥ 80 dB
- Frequency deviation: ΔF ± 75 KHz … ± 100 KHz
- MPX input: Band 40 Hz … 100 KHz, impedance > 2KΩ or 600Ω
- MONO input: 40 Hz … 15 KHz, impedance > 2KΩ or 600Ω, pre-pressure 0/50/75μs
- AUDIO AUX input: 21 KHz … 100 KHz, adjustable from -6dBu to 6dBu
- L and R inputs: Stereocoder, impedance > 2KΩ or 600Ω, pre-noise 0/50/75 μs, adjustable from -12dBu to 12dBu
- Clipper Δf: ON/OFF
- AES/EBU input: Impedance 110 ohms, sensitivity from 0dBFs to – 24dBFs
- RDS input: optional dynamic RDS encoder
STEREO OUTPUT SPECIFICATIONS WITH L/R AND MPX INPUT
- Amplitude/frequency: < ± 0.15 dB (30 Hz – 15 KHz)
- Total harmonic distortion noise: 0.03% at 400 Hz
- AM Noise (MPX input): ≤ – 60dB ref. amplitude modulation 100% of the carrier
- Synchronous AM (MPX input): ≤ – 50 dB ref. amplitude modulation 100% of the carrier.
- S/N: > 70 dB (f=400 Hz with Δf ± 75 kHz)
- Linear crosstalk (L / R input): < – 55 dB (40 Hz – 15 kHz)
CONTROL AND MONITORING
- Local: Graphic display with push buttons
- Remote: SNMP / WEB pages / TLS-TLC
-
- GSM / UMTS / GPRS as an option
GENERAL SPECIFICATIONS
- Mechanical dimensions: W x H x D: 483 mm x 45 mm (1RU) x 350 mm
- Weight: 5 kg
- Power supply: 90-264 VAC with manual switch
- Efficiency: > 45%
ENVIRONMENTAL CONDITIONS
- Max altitude: 4000 m
- Operating temperature range: -5 ÷ 45°C
- Maximum relative humidity: 95% @ 35°C non-condensing
| Brand |
Aqua Broadcast |
|---|---|
| Power output (Watt) |
100 |
| Band |
FM |
| Connector type |
N Connector |
| Rackmount |
1 HE |
